Professional Grade Power and USB2 Extension

Price

$369.00

Valens USB and Power Extender provides seamless extension of USB 2.0 data link and power for distances up to 100 m. PoE technology is used at the host side connection to power the device side and the attached peripheral. Connect and power peripherals on the device side at 5V or 12V using the standard USB-C connection or at 12V using the included DC power cable.

SKU:

R489

Manufactured by

Valens Semiconductor

Israel

Tabs

Overview

System Overview

The EVX6‐USB‐KT‐POE kit extends USB2 and power over a single standard CATx cable for distances of up to 100m / 328ft with data rates up to 480Mb/s. It is a Plug and Play solution that doesn’t require any driver installation. The kit includes a Host-Side Extender that connects to a Computer via a USB cable and a Device-Side Extender that connects to the remote USB peripheral. The Device-Side Extender provides 5V at 2A or 12V at 2A to the peripheral device over a USB‐C cable or 12V at up to 2A via the optional (included) DC power cable, eliminating the need for outlets near the peripheral.

Compact Enclosure enables Easy Integration

At 97.1 x 62 x 21mm (device side) and 103 x 52 x 21mm (host side), the extenders fit into tight spaces. Screw tabs allow simple surface mounting or fastening to a rack shelf. The compact size, ease of mounting, and remote power features make the extender ideal for USB cameras and small peripherals.

A Universal USB and Power Extender

Valens' USB and Power Extender provides USB devices with up to 24W over USB-C, while other devices can receive 12V at 2A via the DC power jack. Take your projects beyond standard USB cable lengths and the limitations of other fixed-length extension solutions. Applications needing cable lengths beyond USB-IF specifications can benefit from a Category 6a cable extension up to 100m (328ft), eliminating the need for AC power interfaces near the peripheral.

Features

Easily extend USB peripherals with field termination up to 100 m / 328 ft.
Two options to power the extended device
Supply auto-negotiated 5/12V power over a single, standard Category cable
External 12V power output for devices that require a separate power-in connector
Streamline room layout and equipment changes with flexible plug-and-play simplicity
Support for all Logitech cameras
Perfect mechanical and electrical fit for the Rally camera
High-speed USB 2.0
Support for all common USB protocols

Applications

Application: USB Camera Extension

Extender - Host Side

Mounting Brackets
USB Connection to the Host/Computer
Status LED
RJ45 CATx Extension Link
48 V Input Power

Extender - Device Side

Optional 12V Power Output (turn 90 degrees counterclockwise to remove cover)
USB‐C Connection to Device / Camera
Status LED
RJ45 CATx Extension Link

Connecting your Extender

Connect the CATx cable from the Host-Side Extender to the Device-Side Extender
Connect the USB‐C to USB‐C Cable from the Device-Side Extender to the USB port of the camera
Connect a USB-C or USB‐A to USB‐C Cable from the Host-Side Extender to your computer
Connect the power adapter from the Host-Side Extender to the wall outlet
The status LED will flash when the computer is turned on and the extension link is established successfully

Troubleshooting

Host Side LED Indicator

LED Off – Indicates there is no power to the Extender. Verify the USB cable is properly connected from the computer to the Host Side Extender.
LED On – Indicates the extender has proper power but there is no data link established. Verify the category cable is properly connected.
Blinking LED – Indicates the link is up and working properly.

Device Side LED Indicator

LED Off – Indicates there is no power supplied to the Device Side Extender. Verify that the 48V power supply is connected to the Host Side Extender and that the category cable is properly connected.
LED On – Indicates the extender has proper power but there is no data link established. Verify that the USB Cable from the Computer is properly connected to the Host Side Extender and that the category cable is properly connected.
Blinking LED – Indicates the link is up and working.

Downloads

Files

Attachment	Size
Datasheet	253.05 KB
Setup Guide	1.38 MB

Specs

Characteristics
Product Dimensions	Host Side: 103mm x 52mm x 21mm (4.06" x 2.05" x 0.83") Device Side: 97.1mm x 62mm x 21mm (3.83" x 2.45" x 0.83")
Host Side Power	Power input (from power supply): 48 VDC / 0.75 A
Device Side Power	Power output from USB-C port: 5V at 2A / 12V at 2A Power output from DC power jack (4mm x 1.7mm barrel connector): 12V at 2A
Compliance	CE, FCC, RoHS
Operating Temperature	0-40°C (32 -- 104°F)
Warranty	12-month limited hardware

Reviews

Add new comment

Kit Includes

Extender – Host Side
Extender – Device Side
48V AC/DC Power Adapter
USB Cable: USB-A to USB-C - 1.5 m (4.9 ft)
USB Cable: USB-C to USB-C - 0.3 m (1 ft)
Device Side 12V DC Power Cable - 0.3 m (1 ft)
Screws for mounting
Documentation
